PositionScrollView

アセット 2@3x

Position Scroll View is pure Swift UI Scroll View which can get or move scroll position.

Features

  • Get scroll position of scroll
  • Vertical, Horizontal, Two Dimensional scroll
  • Move scroll position by code
  • Stick edge of scroll page or follow momentum after scroll ends.

Requirements

  • Xcode 11.6+
  • Swift 5.2+

Install

SwiftPackageManager Add url in the Swit Package Magener tab in Xcode

CocoaPods

pod ‘PositionScrollView’

Usage

PositionScrollView divides whole target view to pages and units to treat scroll position easily. Group 38

And you can get/set position in each ranges. Group 41

Minimal horizontal scroll view example below.

import Foundation
import SwiftUI

/// Extended ScrollView which can controll position
public struct MinimalHorizontalExample: View, PositionScrollViewDelegate {
    /// Page size of Scroll
    var pageSize = CGSize(width: 200, height: 300)

    // Create PositionScrollViewModel
    // (Need to create in parent view to bind the state between this view and PositionScrollView)
    @ObservedObject var psViewModel = PositionScrollViewModel(
        pageSize: CGSize(width: 200, height: 300),
        horizontalScroll: Scroll(
            scrollSetting: ScrollSetting(pageCount: 5, afterMoveType: .stickNearestUnitEdge),
            pageLength: 200 // Page length of direction
        )
    )

    public var body: some View {
        return VStack {
            PositionScrollView(
                viewModel: self.psViewModel,
                delegate: self
            ) {
                HStack(spacing: 0) {
                    ForEach(0...4, id: \.self){ i in
                        ZStack {
                            Rectangle()
                                .fill(BLUES[i])
                                .border(Color.black)
                                .frame(
                                    width: self.pageSize.width, height: self.pageSize.height
                            )
                            Text("Page\(i)")
                                .foregroundColor(Color.white)
                                .font(.system(size: 24, weight: .heavy, design: .default))
                        }
                    }

                }
            }
			  // Get page via scroll object
            Text("page: \(self.psViewModel.horizontalScroll?.page ?? 0)")
			  // Get position via scroll object
            Text("position: \(self.psViewModel.horizontalScroll?.position ?? 0)")
        }
    }

    struct SampleView_Previews: PreviewProvider {
        static var previews: some View {
            return MinimalHorizontalExample()
        }
    }

    // Delegate methods of PositionScrollView
	  // You can monitor changes of position
    public func onScrollStart() {
        print("onScrollStart")
    }
    public func onChangePage(page: Int) {
        print("onChangePage to page: \(page)")
    }

    public func onChangePosition(position: CGFloat) {
        print("position: \(position)")
    }

    public func onScrollEnd() {
        print("onScrollEnd")
    }
}

API Details

ScrollSetting

Setting variables

ValueName Type Default Detail
pageCount* Int - Count of page
initialPage Int 0 Initial page of scroll
unitCountInPage Int 1 Unit count of single page
afterMoveType AfterScrollEndsBehavior .stickToNearestUnitEdge Behavior of scroll move after scroll ends
stickToNearestUnitEdge: Stick nearest unit edge
momentum: It move until momentum disappear.
scrollSpeedToDetect Double 30 Scroll speed to detect

Scroll

Variables

ValueName Type Detail
position CGFloat Position based on the start of page 0
page Int Current page
positionInPage CGFloat Current position based on the start of the page
unit Int Current unit in page
positionInUnit CGFloat Current position based on the start of the unit

Functions

FunctionName Args Detail
moveBy value: CGFloat Move scroll by argment value
moveTo position: CGFloat Move scroll to argment position
moveToPage page: Int
unit: Int = 0
positionInUnit: CGFloat = 0
Move scroll to argument page

PositionScrollViewDelegate

FunctionName Args Detail
onScrollStart - Called when a scroll starts
onChangePosition position: CGFloat Called when position changed
onChangePage page: Int Called when scroll page changed
onChangeUnit unit: Int Called when unit changed
onChangePositionInPage positionInPage: CGFloat Called when position in page changed
onChangePositionInUnit positionInUnit: CGFloat Called when position in unit changed
onScrollEnd - Called when a scroll ends

Contact, Author

Please feel free to contact me. kazuooooo
