LBExpandedCollectionView
This library provides a custom UICollectionView that allows to expand the cells. Provides a simple API to manage collection view appearance.
| Storyboard Setup: |
|---|
|
Example Project
Protocols
Example
class ViewController: UIViewController {
@IBOutlet weak var expandedCollectionView: LBExpandedCollectionView!
override func viewDidLoad() {
super.viewDidLoad()
expandedCollectionView.expandedDelegate = self
expandedCollectionView.expandedDataSource = self
}
}Delegate - LBExpandedCollectionViewDelegate
The Collection Delegate Methods.
@objc public protocol LBExpandedCollectionViewDelegate {
/*
* Scale For Cell At IndexPath
* */
optional func expanded(_ collectionView: LBExpandedCollectionView,
scaleForCellAt indexPath: IndexPath) -> LBExpandedCellScale
/*
* Will Display Cell for Collection Item At IndexPath.
* */
optional func expanded(_ collectionView: LBExpandedCollectionView,
willDisplay cell: UICollectionViewCell, forItemAt indexPath: IndexPath)
/*
* Did End Displaying Cell for Collection Item At IndexPath.
* */
optional func expanded(_ collectionView: LBExpandedCollectionView,
didEndDisplaying cell: UICollectionViewCell, forItemAt indexPath: IndexPath)
/*
* Size For Collection Footer
* */
optional func sizeForFooter(in collectionView: LBExpandedCollectionView) -> CGSize
/*
* Size For Collection Header
* */
optional func sizeForHeader(in collectionView: LBExpandedCollectionView) -> CGSize
/*
* Did Select Collection Item At IndexPath
* */
optional func expanded(_ collectionView: LBExpandedCollectionView, didSelectItemAt indexPath: IndexPath)
}DataSource - LBExpandedCollectionViewDataSource
The Collection Data Source Methods.
@objc public protocol LBExpandedCollectionViewDataSource {
/*
* Number Of Collection Items.
* */
func numberOfItems(in collectionView: LBExpandedCollectionView) -> Int
/*
* View For Collection Header.
* */
optional func viewForHeader(_ collectionView: LBExpandedCollectionView) -> UICollectionReusableView
/*
* View For Collection Footer.
* */
optional func viewForFooter(_ collectionView: LBExpandedCollectionView) -> UICollectionReusableView
/*
* Cell For Collection Item At IndexPath.
* */
func expanded(_ collectionView: LBExpandedCollectionView, cellForItemAt indexPath: IndexPath) -> UICollectionViewCell
} DelegateFlowLayout - LBExpandedCollectionViewDelegateFlowLayout
The Collection Flow Layout Delegate Methods.
@objc public protocol LBExpandedCollectionViewDelegateFlowLayout: LBExpandedCollectionViewDelegate {
/*
* Spacing -> Top \ Bottom
* */
optional func minimumLineSpacing(_ collectionView: LBExpandedCollectionView,
_ collectionViewLayout: LBExpandedCollectionViewFlowLayout) -> CGFloat
/*
* Spacing Left \ Right
* */
optional func minimumInteritemSpacing(_ collectionView: LBExpandedCollectionView,
_ collectionViewLayout: LBExpandedCollectionViewFlowLayout) -> CGFloat
} LBExpandedCellScale
enum LBExpandedCellScale: Int {
case one = 1
case two = 2
case four = 4
}Expanded Cells Design
+-----------+ +---------------------+
| | <-+----- | Scale one |
| 0 | +---------------------+
| | | LBExpandedCellScale |
+-----------+ +---------------------+
+-----------+ +---------------------+
| | <-+----- | Scale two |
| | +---------------------+
| | | LBExpandedCellScale |
| 0 | +---------------------+
| |
| |
| |
+-----------+
+-----------+----------+ +---------------------+
| | <-+----- | Scale four |
| | +---------------------+
| | | LBExpandedCellScale |
| 0 | +---------------------+
| |
| |
| |
+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | | <-+-----| LBExpandedCellScale - |
| 0 | 1 | 2 | | index -> 0 == one |
| | | | | index -> 1 == one |
+-----------+-----------+----------+ | index -> 2 == one |
+-----------------------+
+-----------+-----------+----------+ +-----------------------+
| | | | <-+-----| LBExpandedCellScale - |
| | 1 | 2 | | index -> 0 == two |
| | | | | index -> 1 == one |
| 0 |-----------+----------| | index -> 2 == one |
| | | | | index -> 3 == one |
| | 3 | 4 | | index -> 4 == one |
| | | | +-----------------------+
+-----------+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | | <-+-----| LBExpandedCellScale - |
| | 0 | 2 | | index -> 1 == two |
| | | | | index -> 0 == one |
| 1 |-----------+----------| | index -> 1 == one |
| | | | | index -> 2 == one |
| | 3 | 4 | | index -> 3 == one |
| | | | +-----------------------+
+-----------+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | | <-+-----| LBExpandedCellScale - |
| 0 | 1 | | | index -> 2 == two |
| | | | | index -> 0 == one |
|-----------+-----------| 2 | | index -> 1 == one |
| | | | | index -> 3 == one |
| 3 | 4 | | | index -> 4 == one |
| | | | +-----------------------+
+-----------+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | <-+-----| LBExpandedCellScale - |
| | 1 | | index -> 0 == four |
| | | | index -> 1 == one |
| 0 +----------| | index -> 2 == one |
| | | +-----------------------+
| | 2 |
| | |
+-----------+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | <-+-----| LBExpandedCellScale - |
| | 0 | | index -> 0 == one |
| | | | index -> 1 == four |
| 1 +----------| | index -> 2 == one |
| | | +-----------------------+
| | 2 |
| | |
+-----------+-----------+----------+
+-----------+-----------+----------+ +-----------------------+
| | | <-+-----| LBExpandedCellScale - |
| 0 | | | index -> 0 == one |
| | | | index -> 1 == one |
|-----------+ 2 | | index -> 2 == four |
| | | +-----------------------+
| 1 | |
| | |
+-----------+-----------+----------+Install
The recommended approach for installing LBExpandedCollectionView is the CocoaPods package manager.
Install CocoaPods if not already available:
$ sudo gem install cocoapodsEdit your Podfile and add LBExpandedCollectionView:
platform :ios, '14.0'
use_frameworks!
target 'MyApp' do
pod 'LBExpandedCollectionViewFramework'
endInstall into your project:
$ pod installRequirements
LBExpandedCollectionView requires at least iOS 14 or above.
