JYDropDownMenu

A drop-down menu list as an alternative to UIPickerView.

Installation:

Method 2 (Source files)

Alternatively, you can add all source files in the “Source” folder to your project

Usage

Programmatically

Start by creating an array that contains strings as the elements of the JYDropDownMenu

let items: [String] = ["Item 1", "Item 2", "Item 3", "Item 4", "Item 5"]

Create a new instance of JYDropDownMenu

let dropDownMenu = JYDropDownMenu(frame: CGRect(x: 50, y: 50, width: 260, height: 40), title: "Choose An Item", items: items)

Implement the delegate

dropDownMenu.delegate = self

Add the JYDropDownMenu as a subview.

self.view.addSubview(dropDownMenu)

Use delegate method to determine which item in the array was selected

func dropDownMenu(dropDownMenu: JYDropDownMenu, didSelectMenuItemAtIndexPathRow indexPathRow: Int)

Interface Builder

• From Interface Builder, drap and drop UIView onto your View.
• In Identity Inspector, set custom class JYDropDownMenu.
• Connect the outlet to your source file, e.g. @IBOutlet weak var dropDownMenu: JYDropDownMenu!

Create an array that contains strings as the elements of the JYDropDownMenu

let items: [String] = ["Item 1", "Item 2", "Item 3", "Item 4", "Item 5"]

• Instantiate the JYDropDownMenu

self.dropDownMenu = JYDropDownMenu(frame: self.dropDownMenu.frame, title: "Choose An Item", items: items)

Implement the delegate

self.dropDownMenu.delegate = self

Add the JYDropDownMenu as a subview.

self.view.addSubview(self.dropDownMenu)

Use delegate method to determine which item in the array was selected

func dropDownMenu(dropDownMenu: JYDropDownMenu, didSelectMenuItemAtIndexPathRow indexPathRow: Int)

Customization

Once you have assigned the items and the frame of the JYDropDownMenu, you can customize the look of the menu. The following properties can be changed:

width The width of the menu.

height The height of the menu.

title The title of the menu.

menuBackgroundColor The background color of the menu title. Default is UIColor(red: 247.0/255.0, green: 247.0/255.0, blue: 247.0/255.0, alpha: 1.0)

menuTitleTextAlignment The text alignment of the menu title. Default is NSTextAlignment.Center

menuTitleFont The font of the menu title. Default is UIFont.systemFontOfSize(17.0)

menuItemFont The font of the menu items. Default is UIFont.systemFontOfSize(17.0)

menuRowHeight The cell height of the menu items. Default is UITableViewAutomaticDimension

menuTitleColor The font color of the menu title. Default is darkGrayColor()

menuItemColor The font color of the menu items. Default is darkGrayColor()

License

JYDropDownMenu is available under the MIT License. See the LICENSE for details

Acknowledgements

Because this is the first time I attempted creating a CocoaPods library, I used, among other libraries, BTNavigationDropdownMenu and KSTokenView as inspiration. Kudos to the authors of those libraries.
