dsd# FMMosaicLayout

FMMosaicLayout is a mosiac collection view layout. There are a great number of media-based iOS applications that use UICollectionViewFlowLayout without any modifications. This lends itself to boring presentation, and unengaging interaction. FMMosaicLayout is a step in the right direction. Simply add this pod to your project, set your preferences and it will layout out your collection view cells in pretty mosaics. The algorithm behind this got its inspiration from this blog post.

Usage

FMMosaicLayout is very easy to use. Below is all you need to get going.

- (void)viewDidLoad {
    ...

    FMMosaicLayout *mosaicLayout = [[FMMosaicLayout alloc] init];
    self.collectionView.collectionViewLayout = mosaicLayout;

    ...
}

#pragma mark <FMMosaicLayoutDelegate>

- (NSInteger)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
    numberOfColumnsInSection:(NSInteger)section {

    return 2; // Or any number of your choosing.
}

It's also possible to set the layout via Interface Builder. To see a complete example implementation. Clone the repo, and run pod install from the Example directory. Then open up Example/FMMosaicLayout.xcworkspace.

Customization

In addition to the required protocol method collectionView:layout:numberOfColumnsInSection:, there are several optional methods you can implement from FMMosaicLayoutDelegate. You can see them in action in the example project.

Mosaic Cell Size

- (FMMosaicCellSize)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
        mosaicCellSizeForItemAtIndexPath:(NSIndexPath *)indexPath;

This allows you to specify when you want to place a large or small mosaic cell.

Section Insets

- (UIEdgeInsets)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
        insetForSectionAtIndex:(NSInteger)section;

Here you can specify a custom UIEdgeInsets for each section.

Interitem Spacing

- (CGFloat)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
        interitemSpacingForSectionAtIndex:(NSInteger)section;

Here you can specify the spacing between cells.

Header and Footer Support

Below are the optional methods you can make use of to customize your headers and footers. The first methods are to set the height of your header/footers.

- (CGFloat)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
 heightForHeaderInSection:(NSInteger)section;

- (CGFloat)collectionView:(UICollectionView *)collectionView layout:(FMMosaicLayout *)collectionViewLayout
 heightForFooterInSection:(NSInteger)section;

If you want your header and/or to overlay your mosaic cells implement the following methods below in your delegate and have them return YES. The default is NO.

- (BOOL)headerShouldOverlayContentInCollectionView:(UICollectionView *)collectionView
                                            layout:(FMMosaicLayout *)collectionViewLayout;

- (BOOL)footerShouldOverlayContentInCollectionView:(UICollectionView *)collectionView
                                            layout:(FMMosaicLayout *)collectionViewLayout;

Installation

License

FMMosaicLayout is available under the MIT license. See the LICENSE file for more info.
